| Camera |
Image Sensor |
1/2.7” CMOS |
| Max. Resolution |
5MP, 2880 (H) × 1620 (V) |
| Scanning System |
Progressive |
| Electronic Shutter Speed |
Auto/Manual 1/3 s–1/100,000 s |
| Min. Illumination |
0.001Lux(Illuminator off); 0Lux (Illuminator on) |
| S/N Ratio |
> 56 dB |
| Illumination Distance |
Warm light distance 40 m, IR distance 50m |
| Illuminator Control |
Auto; Manual |
| Lens |
Lens Type |
Fixed-Focal |
| Focal Length |
2.8mm/3.6mm |
| Max. Aperture |
F1.0 |
| Field of View |
2.8mm Horizontal: 111°,Vertical:59°,Diagonal:134°
3.6mm Horizontal: 90°,Vertical:48°,Diagonal: 108° |
| Iris Type |
Auto |
| Intelligence |
Smart Motion Detection |
Yes |
| Perimeter Protection |
Intrusion,Tripwire(Support the classification of Vehicle, Human and Non-Motor) |
| Face Detection |
Yes |
| Object Detection |
NA |
| People Counting |
NA |
| Heat Map |
NA |
| AI Search |
Work together with NVR |
| Video |
Compression |
H.264H; H.264M; H.264B; H.265 |
| Smart Compression |
H.264H+; H.264M+; H.264B+; H.265+ |
| Video Frame Rate |
Main Stream: 5MP (1 fps–25/30 fps) |
| Sub Stream: D1 (1 fps–25/30 fps) |
| Third Stream: 720P (1 fps–25/30 fps) |
| Stream Capability |
3 Streams |
| Bit Rate Control |
CBR/VBR |
| Video Bit Rate |
H.264: 3 Kbps–20480 Kbps |
| H.265: 3 Kbps–20480 Kbps |
| Day/Night |
Color/B/W |
| BLC |
Yes |
| HLC |
Yes |
| WDR |
120 dB |
| White Balance |
Yes |
| Gain Control |
Auto/Manual |
| Noise Reduction |
3D NR |
| Motion Detection |
OFF/ON (4 Areas, rectangular) |
| Image Rotation |
90°/180°/270° |
| Mirror |
Yes |
| Privacy Masking |
4 Areas |
| Audio |
Built-in Mic |
Yes |
| Built-in Speaker |
Yes |
| Two-way talk |
Yes |
| Audio Compression |
G.711a; G.711Mu; G.726; G.726ASF |
| Alarm |
Arming/Disarming |
Yes |
| Sound Alarm |
Yes |
| Light Alarm |
Yes |
| Alarm Event |
Disconnection; IP Conflict; No SD Card; Capacity Warning; SD Card Error |
| Network |
Network |
RJ-45 (10/100 Base-T) |
| SDK and API |
Yes |
| Network Protocol |
TCP/IP;UDP;HTTP;IGMP;ICMP;DHCP;RTP/RTSP;DNS;DDNS;FTP;NTP;PPPOE;UPNP;SMTP |
| Interoperability |
ONVIF; CGI; P2P |
| User/Host |
20 (Total bandwidth: 80 M) |
| Storage |
FTP; Micro SD card (support max. 256 G/FAT32) |
| Browser |
IE: IE8 and later; Chrome; Firefox |
| Management Software |
PC Software(SVMS), APP(Zanuo) |
| Mobile Client |
IOS; Android |
| Port |
Audio Input |
1 channel |
| Audio Output |
1 channel |
| Alarm Input |
1 channel |
| Alarm Output |
1 channel |
| Power |
Power Supply |
12V DC (±30%)/PoE (802.3af) |
| Power Consumption |
Basic: 2.8 W; Max. 5.5W |
| Environment |
Operating Conditions |
–30°C to +60°C (–22°F to +140°F)/Less than 95% RH |
| Storage Conditions |
–40°C to +60°C (–40°F to +140°F) |
| Protection Grade |
IP67 |
| Structure |
Casing |
Metal |
| Dimensions |
224 mm × 77mm × 76mm |
| Net Weight |
760g |
