Camera
|
|
Pixel
|
2 MP
|
|
Image Sensor
|
2MP CMOS
|
|
Max. Resolution
|
1920 (H) × 1080 (V)
|
|
Scanning System
|
Progressive
|
|
Electronic Shutter Speed
|
PAL: 1/25 s–1/100,000 s
NTSC: 1/30 s–1/100,000 s
|
|
Min. Illumination
|
0.04 lux@F2.0 (Color, 30 IRE)
0.004 lux@F2.0 (B/W, 30 IRE)
0 lux (Illuminator on)
|
|
S/N Ratio
|
>65 dB
|
|
Illumination Distance
|
20 m (65.62 ft)
|
|
Illuminator On/Off Control
|
Auto/Manual
|
|
Illuminator Number
|
2 (IR light)
|
|
Pan/Tilt/Rotation Range
|
Pan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360°
|
|
Lens
|
|
Lens Type
|
Fixed-focal
|
|
Lens Mount
|
M12
|
|
Focal Length
|
2.8 mm; 3.6 mm; 6 mm
|
|
Max. Aperture
|
F2.0
|
|
Field of View
|
2.8 mm: H: 100°; V: 53°; D: 120°
3.6 mm: H: 82°; V: 42°; D: 98°
6 mm: H: 53°; V: 30°; D: 60°
|
|
Iris Control
|
Fixed
|
|
Close Focus Distance
|
2.8 mm: 0.6 m (1.97 ft)
3.6 mm: 1.0 m (3.28 ft)
6 mm: 2.0 m (6.56 ft)
|
|
DORI Distance
|
Lens
|
Detect
|
Observe
|
Recognize
|
Identify
|
|
2.8 mm
|
46.9 m
(153.87 ft)
|
18.8 m
(61.68 ft)
|
9.4 m
(30.84 ft)
|
4.7 m
(15.42 ft)
|
|
3.6 mm
|
60.9 m
(199.80 ft)
|
24.3 m
(79.72 ft)
|
12.2 m
(40.03 ft)
|
6.1 m
(20.01 ft)
|
|
6 mm
|
82.8 m
(271.65 ft)
|
33.1 m
(108.60 ft)
|
16.6 m
(54.46 ft)
|
8.3 m
(27.23 ft)
|
|
Video
|
|
Video Frame Rate
|
CVI:
PAL: 1080p@25 fps; 720p@25 fps
NTSC: 1080p@30 fps; 720p@30 fps
TVI:
PAL: 1080p@25 fps; 720p@25 fps
NTSC: 1080p@30 fps; 720p@30 fps
AHD:
PAL: 1080p@25 fps; 720p@25 fps
NTSC: 1080p@30 fps; 720p@30 fps
CVBS:
PAL: 960H
NTSC: 960H
|
|
Resolution
|
1080p (1920 × 1080); 720p (1280 × 720); 960H (960 × 576/960 × 480)
|
|
Day/Night
|
Auto (ICR)/Color/B/W
|
|
BLC
|
BLC; HLC; DWDR
|
|
WDR
|
DWDR
|
|
White Balance
|
Auto; Area white balance
|
|
Gain Control
|
Auto/Manual
|
|
Noise Reduction
|
2D NR
|
|
Smart Illumination
|
Yes
|
|
Mirror
|
Yes
|
|
Privacy Masking
|
Off/On (8 areas, rectangle)
|
|
Certification
|
|
Certifications
|
CE (EN55032:2015, EN61000-3-2:2014, EN61000-3-3:2013, EN55024:2010+A1:2015, EN55035:2017, EN50130-4:2011+A1:2014, EN62368-1:2014+A11:2017)
FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)
|
|
Port
|
|
Video Output
|
Video output choices of CVI/TVI/AHD/CVBS by one BNC port
|
|
Power
|
|
Power Supply
|
12 VDC ± 30%
|
|
Power Consumption
|
Max. 2.7 W (12 VDC, IR on)
|
|
Environment
|
|
Operating Temperature
|
–40 °C to +60 °C (–40 °F to 140 °F)
|
|
Operating Humidity
|
<95% (RH), non-condensing
|
|
Storage Temperature
|
–40 °C to +60 °C (–40 °F to +140 °F)
|
|
Protection
|
IP67
|
|
Structure
|
|
Casing
|
Plastic
|
|
Product Dimensions
|
149.3 mm × 69.8 mm × 69.8 mm (5.88" × 2.75" × 2.75")
|
|
Packaging Dimensions
|
164 mm × 79 mm × 90 mm (6.46" × 3.11" × 3.54")
|
|
Net Weight
|
0.14 kg (0.31 lb)
|
|
Gross Weight
|
0.17 kg (0.37 lb)
|
|
Installation
|
Wall mount; ceiling mount; horizontal pole mount
|
