| Sensor: |
1/3 " Progressive Scan CMOS |
| Matrix size: |
4 Mpx |
| Resolution: |
2688 x 1520 - 4 Mpx ,
2560 x 1440 - 3.7 Mpx ,
2304 x 1296 - 3 Mpx ,
1920 x 1080 - 1080p
1280 x 960 - 1.3 Mpx
1280 x 720 - 720p |
| Lens: |
2.8 ... 12 mm - Motozoom |
| View angle: |
- 98 ° ... 31 ° (manufacturer data)
- 92 ° ... 31 ° (our tests result)
|
| Compression: |
H.265+ / H.265 / H.264+ / H.264 / MJPEG |
| Range of IR illumination: |
50 m |
| Alarm inputs / outputs: |
 |
| Main stream frame rate: |
20 fps @ 4 Mpx
25 fps @ 3.7 Mpx |
| Network interface: |
10/100 Base-T (RJ-45) |
| Network protocols: |
IPv4/IPv6, HTTP, HTTPS, TCP, ARP, RTSP, RTP, UDP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, Multicast, ICMP, IGMP, NFS, PPPoE, IEEE 802.1x |
| Audio: |
 |
| WEB Server: |
Built-in |
| Memory card slot: |
Micro SD memory cards up to 256GB support (possible local recording) |
| Max. number of on-line users: |
20 |
| ONVIF: |
18.12 |
| Mobile phones support: |
Port no.: 37777 or access by a cloud (P2P)
- Android: Free application DMSS
- iOS (iPhone): Free application DMSS
|
| Default admin user / password: |
admin / -
The administrator password should be set at the first start |
| Default IP address: |
192.168.1.108 |
| Web browser access ports: |
80, 37777 |
| PC client access ports: |
37777 |
| Mobile client access ports: |
37777 |
| Port ONVIF: |
80 |
| RTSP URL: |
rtsp://admin:haslo@192.168.1.108:554/cam/realmonitor?channel=1&subtype=0 - Main stream
rtsp://admin:haslo@192.168.1.108:554/cam/realmonitor?channel=1&subtype=1 - Sub stream |
| RS-485 interface: |
 |
| Main features: |
- WDR - 120 dB - Wide Dynamic Range
- 3D-DNR - Digital Noise Reduction
- ROI - improve the quality of selected parts of image
- BLC - Back Light Compensation
- HLC - High Light Compensation (spot)
- ICR - Movable InfraRed filter
- AGC - Automatic Gain Control
- Motion Detection - max. 4 zones
- Privacy zones - max. 4
- Auto White Balance
- Mirror - Horizontal mirror image
|
| Power supply: |
- PoE (802.3af),
- 12 V DC / 620 mA
|
| Power consumption: |
< 7.4 W |
| Housing: |
Compact, Metal |
| Color: |
White |
| "Index of Protection": |
IP67 |
| Operation temp: |
-30 °C ... 60 °C |
| Supported languages: |
Polish, English, Czech, French, Spanish, Dutch, German, Portuguese, Russian, Italian |
| Weight: |
0.84 kg |
| Dimensions: |
244 x 90 x 90 mm |
| Manufacturer / Brand: |
DAHUA |
