Basic
|
|
Layer
|
Layer 2
|
|
Switching Capacity
|
4.8 Gbps
|
|
Packet Forwarding Rate
|
3.57 Mpps
|
|
Description of Function Slots
|
Port 1-4: 4 × RJ-45 10/100 Mbps (PoE);
Port 5-6: 2 × SFP 1000 Mbps (uplink)
|
|
Operating Temperature
|
–30 °C to +65 °C (–22 °F to +149 °F)
|
|
Operating Humidity
|
10%–90% (RH), non-condensing
|
|
Protection
|
IP30; IK06
|
|
Storage Temperature
|
–40 °C to +85 °C (–40 °F to +185 °F)
|
|
Storage Humidity
|
5%–95% (RH), non-condensing
|
|
Power Supply
|
External dual power supply (terminal block and DC): 48–57 VDC, 1.354–1.14 A
|
|
Included Power Adapter
|
Yes
|
|
Power Consumption
|
Idling: 1.3 W
Full load: 65 W
|
|
Statics Protection
|
Air discharge: 8 kV;
Contact discharge: 6 kV
|
|
Lightning Protection (Ethernet Port)
|
Common mode: 6 kV;
Differential mode: 2 kV
|
|
Net Weight
|
0.32 kg (0.71 lb)
|
|
Gross Weight
|
0.87 kg (1.92 lb)
|
|
Product Dimensions
|
154.3 mm × 110.4 mm × 30 mm (6.07" × 4.35" × 1.18") (L × W × H)
|
|
Packaging Dimensions
|
266 mm × 239 mm × 77 mm (10.47" × 9.41" × 3.03") (L × W × H)
|
|
Casing Material
|
Iron
|
|
Installation
|
Desktop mount;
DIN-rail mount
|
|
Certifications
|
CE
|
|
PoE
|
|
PoE
|
Yes
|
|
PoE Power
|
Port 1 ≤60 W, Port 2-4 ≤30 W, total ≤60 W
|
|
PoE Protocol
|
IEEE 802.3af; IEEE 802.3at; Hi-PoE
|
|
PoE Power Consumption Management
|
PoE power consumption management;
PoE power on/off;
Turns off PoE if overload is detected;
Green PoE
|
|
PoE Pin Assignment
|
1, 2, 4, 5 (V+), 3, 6, 7, 8 (V-)
|
|
Long Distance PoE Transmission
|
Yes
|
|
PoE Watchdog
|
Yes
|
|
Hardware
|
|
DIP Switch
|
Managed Mode: Switches between managed and unmanaged mode. Managed mode includes local web management and cloud management. It is on by default.
Extend Mode: The transmission distance of ports 1–4 can reach up to 250 meters. The negotiation speed can be reduced to 10 Mbps.
PoE Watchdog: Monitors the flow of data traffic for ports 1–4. If PoE fails for any of the ports and there is no traffic for 2 minutes, the failed ports will be restarted.
|
|
Reset Button
|
1
|
|
Performance
|
|
MTBF
|
2,020,305.28 hours
|
|
Packet Buffer Size
|
4 Mbit
|
|
Jumbo Frame
|
9216 Byte
|
|
MAC Table Size
|
8K
|
|
Total Static MAC Addresses
|
16
|
|
Flash
|
2 MB
|
|
Communication Standard
|
IEEE 802.3; IEEE 802.3u; IEEE 802.3x; IEEE 802.3ab; IEEE 802.3z
|
|
VLAN Number
|
32
|
|
Traffic Limit Granularity
|
1 Mbps
|
|
Feature
|
|
LLDP
|
Yes
|
|
VLAN Function
|
IEEE 802.1Q VLAN
|
|
Port Feature
|
Supports IEEE 802.3x Flow Control;
Supports Unknown Unicast Suppression;
Supports Multicast Storm Control;
Supports Broadcast Storm Control;
Supports MAC+Port Binding;
Supports Loop Prenvention
|
|
Mirror
|
Local Port Mirroring;
N:1 Mirroring
|
|
Reliability
|
LLDP
|
|
DHCP Function
|
DHCP Client
|
|
Security
|
Port Isolation
|
|
Equipment Management
|
Web Management
Cloud Management
Logs
Fault Alarm
|
|
General
|
|
Packing List
|
1 × User Manual;
1 × Legal and Regulatory Information;
1 × Power Cord;
1 × Power Adapter;
1 × Terminal Block
|
