| Camera |
|
| Image Sensor |
1/2.9" CMOS |
| Max. Resolution |
2560 (H) × 1440 (V) |
| ROM |
128 MB |
| RAM |
128 MB |
| Scanning System |
Progressive |
| Electronic Shutter Speed |
Auto/Manual 1/3 s–1/100,000 |
| Min. Illumination |
0.03 lux@F2.0 (Color, 30 IRE) |
| |
0.003 lux@F2.0 (B/W, 30 IRE) |
| |
0 lux (Illuminator on) |
| S/N Ratio |
>56 dB |
| Illumination Distance |
Up to 30 m (98.43 ft) (IR) |
| Illuminator On/Off Control |
Auto;Manual |
| Illuminator Number |
1 (IR LED) |
| Angle Adjustment |
Pan: 0° to 360° |
| |
Tilt: 0° to 90° |
| |
Rotation: 0° to 360° |
| Lens |
|
| Lens Type |
Fixed-focal |
| Lens Mount |
M12 |
| Focal Length |
2.8 mm; 3.6 mm |
| Max. Aperture |
F2.0 |
| Field of View |
2.8 mm: H: 95°; V: 53°; D: 110° |
| |
3.6 mm: H: 78°; V: 43°; D: 92° |
| Iris Control |
Fixed |
| Close Focus Distance |
2.8 mm: 0.9 m (2.95 ft) |
| |
3.6 mm: 1.3 m (4.27 ft) |
| |
|
| Intelligence |
|
| Human Detection |
Support the classification and accurate detection of
human |
| Smart Search |
Work together with Smart NVR to perform refine
intelligent search, event extraction and merging to
event videos |
| Video |
|
| Video Compression |
H.265; H.264; H.264H; H.264B; MJPEG (Only supported
by sub stream) |
| Smart Codec |
Smart H.265+; Smart H.264+ |
| Video Frame Rate |
Main stream: 2560 × 1440@(1–25/30 fps)
sub stream: 704 × 576@(1–25 fps)/704 × 480@(1–30
fps)
*The values above are the max. frame rates of
each stream; for multiple streams, the values will be
subjected to the total encoding capacity. |
| Stream Capability |
2 streams |
| Resolution |
4M (2560 × 1440); 3M (2304 × 1296); 1080p (1920 ×
1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 ×
576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 ×
240) |
| Bit Rate Control |
CBR/VBR |
| Video Bit Rate |
H.264: 32 kbps–4096 kbps;
H.265: 12 kbps–4096 kbps |
| Day/Night |
Auto(ICR)/Color/B/W |
| BLC |
Yes |
| HLC |
Yes |
| WDR |
120 dB |
| White Balance |
Auto; natural; street lamp; outdoor; manual; regional
custom |
| Gain Control |
Auto/Manual |
| Noise Reduction |
3D NR |
| Motion Detection |
OFF/ON (4 areas, rectangular) |
| Region of Interest (RoI) |
Yes (4 areas) |
| Smart Illumination |
Yes |
| Image Rotation |
0°/180° |
| Mirror |
Yes |
| Privacy Masking |
4 areas |
| Audio |
|
| Built-in MIC |
Yes, built-in Mic |
| Audio Compression |
G.711a; G.711Mu; PCM; G.726 |
| Alarm |
|
| Alarm Event |
No SD card; SD card full; SD card error; network
disconnection; IP conflict; illegal access; motion
detection; video tampering; audio detection; SMD
(human) |
| Network |
|
| Network Port |
RJ-45 (10/100 Base-T) |
| SDK and API |
Yes |
| Network Protocol |
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP;
RTMP; SMTP; FTP; DHCP; DNS; DDNS; NTP; Multicast;
ICMP; IGMP; P2P; Auto Register |
| Interoperability |
ONVIF (Profile S; Profile G; Profile T); CGI |
| User/Host |
6 (Total bandwidth: 24 M) |
| Storage |
FTP; Micro SD card (support max. 256 GB) |
| Browser |
IE; Chrome; Firefox |
| Management Software |
Smart PSS Lite; DSS; DMSS; DoLynk Care |
| Mobile Client |
iOS;Android |
| Cyber Security |
Video encryption;Configuration
encryption;Digest;WSSE;Account lockout;Security
logs;Generation and importing of
X.509 certification;HTTPS;Trusted boot;Trusted
execution;Trusted upgrade |
| Certification |
|
| Certifications |
CE-LVD: EN62368-1;
CE-EMC: Electromagnetic Compatibility Directive
2014/30/EU |
| Power |
|
| Power Supply |
12 VDC/PoE (802.3af) |
| Power Consumption |
Basic: 2.1 W (12 VDC); 2.7 W (PoE);
Max.: 4.4 W (12 VDC); 4.9 W (PoE) (H.265 + intelligence
on + WDR+ IR intensity) |
| Environment |
|
| Operating Temperature |
–40 °C to +60 °C (–40 °F to +140 °F) |
| Operating Humidity |
≤95% (RH), non-condensing |
| Storage Temperature |
–40 °C to +60 °C (–40 °F to +140 °F) |
| Storage Humidity |
≤95% (RH), non-condensing |
| Protection |
IP67 |
| Structure |
|
| Casing Material |
Metal + Plastic |
| Product Dimensions |
180.4 mm × 70 mm × 70 mm (7.10" × 2.76" × 2.76") (L ×
W × H) |
| Net Weight |
0.31 kg (0.68 lb) |
| Gross Weight |
0.42 kg (0.93 lb) |
